LM270WQ1-SDC2
LM270WQ1-SDC2 Mōhiohio Taketake
| Tauira tauira | LM270WQ1-SDC2 |
|---|---|
| Pae Waitohu | LG Display |
| Tuhinga | a-Si TFT-LCD ,27.0 inch, 2560×1440 |
| Momo Raraunga | a-Si TFT-LCD |
| LM270WQ1-SDC2 Utu | Tono Tono me te Waa Whakahaere |
| Aratau Tauira | LM270WQ1 (SD)(C2) |
| Tae Mahi | 0 ~ 50 °C |
| Haumaru Ruinga | -20 ~ 60 °C |
| Nga korero | For Apple |
LM270WQ1-SDC2 Ngā Hangarau Hangarau
| Whakatau Whakamutunga | 2560(RGB)×1440 (Quad-HD) |
|---|---|
| Pihikete Pika | RGB Vertical Stripe |
| Pihanga Pika | 108 PPI |
| Whakaaro Ratonga | 16:9 (H:V) |
| Factor Puka | Flat Rectangle Display |
| Poutoro Poto | 0.0777×0.2331 mm (H×V) |
| Pika Pihanga | 0.2331×0.2331 mm (H×V) |
| Taumaha | 4.60Kgs (Typ.) |
| Mata | Glare (Haze 0%), Hard coating (2H), Antireflection |
| Area Mahinga | 596.736×335.664 mm (H×V) |
| Bezel Area | 601.7×340.7 mm (H×V) |
| Rautaki Whakahuahua | 630×376.13 mm (H×V) |
| Whakaaturanga Whakahuahua | 16.36/22.3 (Typ./Max.) mm |
| Horo me nga Poaka | Side mounting holes (14-M3) on left, right, up, down bezel |
| Nga Whenua Whenua ranei | Landscape type |
| Pae Tae | Without |
LM270WQ1-SDC2 Ngā Āhuahira Arotahi
| Whakaatu Aratau | H-IPS, Normally Black, Transmissive |
|---|---|
| Maama | 420 cd/m² (Typ.) |
| Whakatau Ratonga | 1000 : 1 (Typ.) (Transmissive) |
| Whakaatu Tae | 16.7M (8-bit) |
| Tae Tae | sRGB |
| Wā Whakautu | 6.5/7.5 (Typ.)(Tr/Td) |
| Tirohia te Angle | 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) |
| Tirohanga Whakahaere | Symmetry |
| Te tae matomato Kakano | Wx:0.308; Wy:0.325 |
| Maama te Maama | N |
LM270WQ1-SDC2 Hangarau Hangarau
| Putanga Poutū | 60Hz |
|---|---|
| Whakaaro Whakamuri | No |
| Te Whakamahinga Mana Utu | 95.51W (Max.) |
LM270WQ1-SDC2 Pūnaha Ataata
| Tumuaki Poko | Edge light type (Left and Right) |
|---|---|
| Momo Momo | WLED |
| He nui te raima | 6 strings |
| Hanga Hangaira | 6 strings |
| Te wa mo te rama | 39K(Min.) (Hours) |
| Penehi Rama | 31±5V |
| Whakaoho Whakaoho Rama | 75.6/80.15W (Typ./Max.) |
| Momo Atanga | Connector |
| Papa Pouaka Papa | No |
LM270WQ1-SDC2 Atanga Waitohu
| Waitohu Waitohu | eDP |
|---|---|
| Pato Waitohu | eDP (4 Lanes) |
| Putanga o te Whakauru mo te Paewhiri | 12.0V (Typ.) |
| Te Whakauru Naianei mo te Paewhiri | 1.28/1.48A (Typ./Max.) |
| Whakaoranga Mana Whakahaere | 15.36/17.70W (Typ./Max.) |
| Momo Atanga | Connector |
| Waehere Atanga | |
| Atanga Waitohu | JAE - FI-X30SSL-HF, Pitch:1.0 mm, Pin:30 pins |
