BRS650H3
BRS650H3 Mōhiohio Taketake
| Tauira tauira | BRS650H3 |
|---|---|
| Pae Waitohu | BERISE |
| Tuhinga | a-Si TFT-LCD ,65 inch, 1920×1080 |
| Momo Raraunga | a-Si TFT-LCD |
| BRS650H3 Utu | Tono Tono me te Waa Whakahaere |
| Tae Mahi | 0 ~ 50 °C |
| Haumaru Ruinga | -20 ~ 60 °C |
| Nga korero | Surface Luminance, white 3D: 700 cd/m² |
BRS650H3 Ngā Hangarau Hangarau
| Whakatau Whakamutunga | 1920(RGB)×1080 (FHD) |
|---|---|
| Pihikete Pika | RGB Vertical Stripe |
| Pihanga Pika | 34 PPI |
| Whakaaro Ratonga | 16:9 (H:V) |
| Factor Puka | Flat Rectangle Display |
| Poutoro Poto | 0.248×0.744 mm (H×V) |
| Pika Pihanga | 0.744×0.744 mm (H×V) |
| Taumaha | 18.5/19.4Kgs (Typ./Max.) |
| Mata | Antiglare (Haze 1%), Hard coating (2H) |
| Area Mahinga | 1428.5×803.5 mm (H×V) |
| Rautaki Whakahuahua | 1444.9×823.7 mm (H×V) |
| Whakaaturanga Whakahuahua | 38.3 (Typ./Max.) mm |
| Nga Whenua Whenua ranei | Landscape type |
| Pae Tae | Without |
BRS650H3 Ngā Āhuahira Arotahi
| Whakaatu Aratau | IPS, Normally Black, Transmissive |
|---|---|
| Maama | 2500 cd/m² (Typ.) |
| Whakatau Ratonga | 1400 : 1 (Typ.) (Transmissive) |
| Whakaatu Tae | 16.7M/1.06B (8-bit / 8-bit + Dithering) |
| Tae Tae | 72% NTSC (CIE1931) |
| Tirohia te Angle | 89/89/89/89 (Min.)(CR≥10) (L/R/U/D) |
| Tirohanga Whakahaere | Symmetry |
| Te tae matomato Kakano | Wx:0.281; Wy:0.288 |
| Te Maama White | 1.54 (Max.)(9 points) |
| 3D Whakaatu | |
| Maama te Maama | Y |
BRS650H3 Hangarau Hangarau
| Putanga Poutū | 120Hz |
|---|---|
| Whakaaro Whakamuri | No |
| Te Whakamahinga Mana Utu | 345W (Typ.) |
BRS650H3 Pūnaha Ataata
| Tumuaki Poko | Direct light type |
|---|---|
| Momo Momo | WLED |
| Te wa mo te rama | 30K(Min.) (Hours) |
| Penehi Rama | 20.8/22.8/24.9V (Min./Typ./Max.) |
| Whakaoho Whakaoho Rama | 340/345W (Typ./Max.) |
| Momo Atanga | Connector |
| Papa Pouaka Papa | No |
BRS650H3 Atanga Waitohu
| Waitohu Waitohu | LVDS |
|---|---|
| Pato Waitohu | LVDS (4 ch, 8/10-bit) |
| Putanga o te Whakauru mo te Paewhiri | 12.0V (Typ.) |
| Te Whakauru Naianei mo te Paewhiri | 270/351mA (Typ./Max.) |
| Whakaoranga Mana Whakahaere | 3.24/4.21W (Typ./Max.) |
| Momo Atanga | Connector |
| Atanga Waitohu | JAE - FI-RXE51S-HF, Pitch:0.5 mm, Pin:51 pins |
