LQ10D36A
LQ10D36A Mōhiohio Taketake
| Tauira tauira | LQ10D36A |
|---|---|
| Pae Waitohu | SHARP |
| Tuhinga | a-Si TFT-LCD ,10.4 inch, 640×480 |
| Momo Raraunga | a-Si TFT-LCD |
| LQ10D36A Utu | Tono Tono me te Waa Whakahaere |
| Tae Mahi | -10 ~ 65 °C |
| Haumaru Ruinga | -30 ~ 70 °C |
LQ10D36A Ngā Hangarau Hangarau
| Whakatau Whakamutunga | 640(RGB)×480 (VGA) |
|---|---|
| Pihikete Pika | RGB Vertical Stripe |
| Pihanga Pika | 76 PPI |
| Whakaaro Ratonga | 4:3 (H:V) |
| Factor Puka | Flat Rectangle Display |
| Poutoro Poto | 0.110×0.330 mm (H×V) |
| Pika Pihanga | 0.330×0.330 mm (H×V) |
| Taumaha | 520g (Max.) |
| Mata | Antiglare, Hard coating (3H) |
| Area Mahinga | 211.2×158.4 mm (H×V) |
| Bezel Area | 214.6×162.4 mm (H×V) |
| Rautaki Whakahuahua | 246.5×179.4 mm (H×V) |
| Whakaaturanga Whakahuahua | 11.0 (Max.) mm |
| Horo me nga Poaka | Face mounting holes (2-Φ3.4, 2-R1.7×4.4) on left, right bezel |
| Nga Whenua Whenua ranei | Landscape type |
| Pae Tae | Without |
LQ10D36A Ngā Āhuahira Arotahi
| Whakaatu Aratau | TN, Normally White, Transmissive |
|---|---|
| Maama | 200 cd/m² (Typ.) |
| Whakatau Ratonga | 500 : 1 (Typ.) (Transmissive) |
| Whakaatu Tae | 262K (6-bit) |
| Wā Whakautu | 10/25 (Typ.)(Tr/Td) |
| Tirohia te Angle | 70/70/50/60 (Typ.)(CR≥10) (L/R/U/D) |
| Tirohanga Whakahaere | 6 o'clock |
| Te tae matomato Kakano | Wx:0.313; Wy:0.329 |
| Te Maama White | 1.45 (Max.)(5 points) |
| Maama te Maama | N |
LQ10D36A Hangarau Hangarau
| Putanga Poutū | 60Hz |
|---|---|
| Whakaaro Whakamuri | Yes (U/D, L/R) |
LQ10D36A Pūnaha Ataata
| Tumuaki Poko | Edge light type (Top side) |
|---|---|
| Momo Momo | CCFL |
| He nui te raima | 1 pcs |
| Hanga Hangaira | Straight |
| Te wa mo te rama | 50K(Typ.) (Hours) |
| Whakapakahia te Papa | Replaceable |
| Penehi Rama | 500V (Typ.) |
| Rama i teianei | 2.0/6.0/6.5mA (Min./Typ./Max.) |
| Nga Mahinga Mahi Paerewa | 20/35/60KHz (Min./Typ./Max.) |
| Aratau Whakaoho Maama | 950/1400/1500V (Max.)(Ta=+25/0/-10.0℃) |
| Whakaoho Whakaoho Rama | 3.0W (Typ.) |
| Momo Atanga | Connector |
| Papa Pouaka Papa | No |
LQ10D36A Atanga Waitohu
| Waitohu Waitohu | TTL |
|---|---|
| Pato Waitohu | Parallel RGB (1 ch, 6-bit) |
| Putanga o te Whakauru mo te Paewhiri | 3.3/5.0V (Typ.)(VCC) |
| Te Whakauru Naianei mo te Paewhiri | 210/140mA (Typ.)(ICC) |
| Putanga mo nga Whakaatu Whakaaturanga | VIL≤0.8V; 2.1V≤VIH |
| Momo Atanga | Connector |
| Atanga Waitohu | HRS - DF9MA-31P-1V(32), Pitch:1.0 mm, Pin:31 pins |
